Model: TL-165 Micro Piston Nebulizer
Power supply voltage: 5VDC
Power: 3W
Atomization rate: 0.25-0.5ml/min
Noise: 30dBA
Warranty period: 3 years
Product Description
DC motor atomizer is an efficient and precise atomization device. It is driven by a DC motor to instantly crush liquids (such as water, medicine, essential oils, etc.), forming extremely fine and uniform micron sized mist particles.
● Fine atomization: The generated mist particles have a small diameter (usually 1-5 microns), are evenly distributed, and are easy to absorb and diffuse.
● Silent and low-noise: runs smoothly and quietly, far exceeding traditional compression atomizers, providing a better user experience.
● Strong controllability: By adjusting the voltage or signal, the atomization amount can be easily controlled to achieve precise output.
● Efficient and energy-saving: DC motors start quickly, consume low energy, and have high energy conversion efficiency.
● Long lifespan: The core components are sturdy and durable, with a simple structure and low maintenance costs.
| Model No. | TL-165 |
| Description | Micro-Piston Nebulizer |
| Motor | DC 5 V (USB powered) |
| Airflow | 3 – 5 LPM |
| Operating Pressure | 5 – 8 PSI |
| Max Compressor Pressure | ≥ 20 PSI |
| Noise Level | ≤ 40 dBA |
| MMAD | 3 µm |
| Nebulizing Rate | 0.15 – 0.25 ml / min |
| MOQ | 1 000 pcs |
| Standard Accessories | 1 × nebulizing cup, 1 × air tube, 1 × adult mask, 1 × child mask, 5 × air filters, 1 × USB cable, instruction manual, gift box, rating label |
| Standard Packing | Each in gift box, then export carton |
| pcs / carton | 20 |
| Carton size | 415 × 345 × 360 mm (0.052 CBM) |
| Net weight / carton | 6.0 kg |
| Gross weight / carton | 8.5 kg |
| Loading qty (reference only) | 20GP: 10 080 pcs / 40GP: 21 600 pcs / 40HQ: 25 320 pcs |
